• Cutting and breaking on the same base - no need of removing the tile. Articulation system enabling to separate tiles at any angle.

• Nickel-plated guides for greater durability.

• Breaking System and backrest bar of injected aluminum;

• Scoring wheel of tungsten carbide. Zinc-coated carbon steel bar.

• Resistant case (optional)

CODE	MODEL	C	H	L	MASTER PACKAGING QTY	EAN 13	UNIT PACKAGE DIMENSIONS	MAXIMUM CUT LENGTH
61366	New Master-90	1095 mm	110 mm	220 mm	2	789 74514 1366 - 3	1095 mm x 221 mm x 115 mm	900 mm
61539	New Master-75	945 mm	110 mm	220 mm	2	789 74514 1539 - 1	945 mm x 221 mm x 115 mm	750 mm

CODE	MODEL	MAXIMUM CUT THICKNESS	MAXIMUM TILE SIZE FOR DIAGONAL CUTTING	SCORING WHEELS FOR REPLACEMENT
61366	New Master-90	12 mm	640 mm x 640 mm	80 Universal/ 100 mm Universal/ Titânio
61539	New Master-75	12 mm	530 mm x 530 mm	80 Universal/ 100 mm Universal/ Titanium
